Uniform Capacity (lb.): 2,000 | Uniform Capacity extended 39-1/4″(lb.): 2000 | Uniform Capacity extended 51-1/4″ (lb.): 1500 |
Uniform Capacity extended 63-1/4″ (lb.): 1000 | Lowered Arm Fully Extended (in.): 15 | Raised Arm Fully Extended (in.): 96 |
Base Length (in.): 94 | Base Width (in.): 29 | Boom Length Minimum/Maximum (in.): 53-1/2 to 77-1/2 |
Design: Counter Balance | Function: Floor Crane | Rigid Caster Quantity/Diameter/Width (in.): (2)8 x 2 |
Rigid Caster Material: Glass-Filled Nylon | Swivel Caster w/Side Brake Quantity/Diameter/Width (in.): (2)8 x 3 | Swivel Caster Material: Phenolic |
Additional information
Weight | 2631 lbs |
---|---|
Dimensions | 159.125 × 29 × 107.5 in |
Color |
Blue |
Brand |
VESTIL |
